NXOpen::Features::Feature Class Reference

Represents a feature on a part
This is an abstract class, and cannot be instantiated. More...

Inheritance diagram for NXOpen::Features::Feature:

Public Types
enum	BooleanType {   BooleanTypeCreate, BooleanTypeUnite, BooleanTypeSubtract, BooleanTypeIntersect,   BooleanTypeEmbossNormalSide = 8, BooleanTypeEmbossOppositeNormalSide }
	Boolean operation type. More...
enum	DiagnosticType { DiagnosticTypeInformation = 1, DiagnosticTypeWarning }
	Diagnostic type. More...
Public Types inherited from NXOpen::NXObject
enum	AttributeType {   AttributeTypeInvalid, AttributeTypeNull, AttributeTypeBoolean, AttributeTypeInteger,   AttributeTypeReal, AttributeTypeString, AttributeTypeTime, AttributeTypeReference,   AttributeTypeAny = 100 }
	Specifies attribute type. More...
enum	DateAndTimeFormat { DateAndTimeFormatNumeric, DateAndTimeFormatTextual }
	Specifies the format of the date and time attribute. More...

Public Member Functions
int	AlgorithmVersion ()
	Returns the algorithm version of the feature
void	ChangeBooleanType ()
	Change Boolean Type Created in NX9.0.0.
NXOpen::Features::IContainerFeature *	ContainerFeature ()
	Returns the container feature for this feature.
void	DeleteClueAlerts ()
	Delete all clue alerts from the features Created in NX8.0.1.
void	DeleteHintAlerts ()
	Delete all clue alerts from the features Created in NX8.0.1.
void	DeleteInformationalAlerts ()
	Delete all informational alerts from the features Created in NX5.0.0.
NXString	FeatureType ()
	Returns the feature type Created in NX3.0.0.
std::vector < NXOpen::Features::Feature * >	GetChildren ()
	Returns the immediate child features.
std::vector< NXOpen::NXObject * >	GetEntities ()
	返回由该特性创建的实体。
std::vector< NXOpen::Expression * >	GetExpressions ()
	Returns the expressions created by the feature.
std::vector< NXString >	GetFeatureClueHintMessages ()
	Returns both clue and hint messages of the feature.
std::vector< NXString >	GetFeatureClueMessages ()
	Returns the feature clue messages.
std::vector< NXString >	GetFeatureErrorMessages ()
	Returns the feature error messages.
std::vector< NXString >	GetFeatureHintMessages ()
	Returns the feature hint messages.
std::vector< NXString >	GetFeatureInformationalMessages ()
	Returns the feature informational messages.
NXString	GetFeatureName ()
	Returns the displayed name of the feature.
std::vector< NXString >	GetFeatureWarningMessages ()
	Returns the feature warning messages.
std::vector < NXOpen::Features::Feature * >	GetParents ()
	Returns the immediate parent features.
std::vector< NXOpen::Section * >	GetSections ()
	Queries a feature for list of its sections.
void	HideBody ()
	Hide the body created by the feature Created in NX3.0.0.
void	HideParents ()
	Hide the body created by the parent feature Created in NX3.0.0.
void	Highlight ()
	Highlight the body created by the feature Created in NX3.0.0.
bool	IsContainedFeature ()
	Returns true if the feature is a contained feature.
bool	IsInternal ()
	Returns true if the feature is internal.
NXOpen::Point3d	Location ()
	Returns the location of the feature Created in NX3.0.0.
void	LogDiagnostic (int errorCode, const NXString &message, NXOpen::Features::Feature::DiagnosticType diagnosticType)
	Log a diagnostic alert for this feature Created in NX8.0.0.
void	LogDiagnostic (int errorCode, const char *message, NXOpen::Features::Feature::DiagnosticType diagnosticType)
	Log a diagnostic alert for this feature Created in NX8.0.0.
void	MakeCurrentFeature ()
	Make current feature Created in NX3.0.0.
void	MakeSketchExternal ()
	Make the parent sketch external for reuse by other features.
void	MakeSketchInternal ()
	Make the parent sketch internal if referenced only by this feature.
void	RemoveForEdit (bool dependent)
	Remove all the feature faces before a NoHistory mode edit.
void	RemoveParameters ()
	Remove Local feature parameters in history free mode.
void	SetGroupActive (bool active)
	Set a feature group as active group.
void	ShowBody (bool moveCurves)
	Show the body created by the feature Created in NX3.0.0.
void	ShowDimensions ()
	Show all feature dimensions of a feature.
void	ShowParents (bool moveCurves)
	Show the body created by the parent feature Created in NX3.0.0.
void	Suppress ()
	Suppress the feature Created in NX3.0.0.
bool	Suppressed ()
	Returns the suppression status of the feature Created in NX3.0.0.
int	Timestamp ()
	Returns the timestamp of the feature Created in NX3.0.0.
void	Unhighlight ()
	Unhighlight the body created by the feature Created in NX3.0.0.
void	Unsuppress ()
	Unsuppress the feature Created in NX3.0.0.
Public Member Functions inherited from NXOpen::NXObject
void	DeleteAllAttributesByType (NXOpen::NXObject::AttributeType type)
	Deletes all attributes of a specific type.
void	DeleteAllAttributesByType (NXOpen::NXObject::AttributeType type, NXOpen::Update::Option option)
	Deletes all attributes of a specific type with the option to update or not.
void	DeleteAttributeByTypeAndTitle (NXOpen::NXObject::AttributeType type, const NXString &title)
	Deletes an attribute by type and title.
void	DeleteAttributeByTypeAndTitle (NXOpen::NXObject::AttributeType type, const char *title)
	Deletes an attribute by type and title.
void	DeleteAttributeByTypeAndTitle (NXOpen::NXObject::AttributeType type, const NXString &title, NXOpen::Update::Option option)
	Deletes an attribute by type and title with the option to update or not.
void	DeleteAttributeByTypeAndTitle (NXOpen::NXObject::AttributeType type, const char *title, NXOpen::Update::Option option)
	Deletes an attribute by type and title with the option to update or not.
void	DeleteUserAttribute (NXOpen::NXObject::AttributeType type, const NXString &title, bool deleteEntireArray, NXOpen::Update::Option option)
	Deletes the first attribute encountered with the given Type, Title and Index.
void	DeleteUserAttribute (NXOpen::NXObject::AttributeType type, const char *title, bool deleteEntireArray, NXOpen::Update::Option option)
	Deletes the first attribute encountered with the given Type, Title and Index.
void	DeleteUserAttributes (NXOpen::NXObject::AttributeType type, NXOpen::Update::Option option)
	Deletes the attributes encountered with the given Type with option to update or not.
virtual NXOpen::INXObject *	FindObject (const NXString &journalIdentifier)
	Finds the NXObject with the given identifier as recorded in a journal.
NXOpen::INXObject *	FindObject (const char *journalIdentifier)
	Finds the NXObject with the given identifier as recorded in a journal.
std::vector < NXOpen::NXObject::AttributeInformation >	GetAttributeTitlesByType (NXOpen::NXObject::AttributeType type)
	Gets all the attribute titles of a specific type.
bool	GetBooleanUserAttribute (const NXString &title, int index)
	Gets a boolean attribute by Title and array Index.
bool	GetBooleanUserAttribute (const char *title, int index)
	Gets a boolean attribute by Title and array Index.
NXOpen::NXObject::ComputationalTime	GetComputationalTimeUserAttribute (const NXString &title, int index)
	Gets a time attribute by Title and array Index.
NXOpen::NXObject::ComputationalTime	GetComputationalTimeUserAttribute (const char *title, int index)
	Gets a time attribute by Title and array Index.
int	GetIntegerAttribute (const NXString &title)
	Gets an integer attribute by title.
int	GetIntegerAttribute (const char *title)
	Gets an integer attribute by title.
int	GetIntegerUserAttribute (const NXString &title, int index)
	Gets an integer attribute by Title and array Index.
int	GetIntegerUserAttribute (const char *title, int index)
	Gets an integer attribute by Title and array Index.
double	GetRealAttribute (const NXString &title)
	Gets a real attribute by title.
double	GetRealAttribute (const char *title)
	Gets a real attribute by title.
double	GetRealUserAttribute (const NXString &title, int index)
	Gets a real attribute by Title and array Index.
double	GetRealUserAttribute (const char *title, int index)
	Gets a real attribute by Title and array Index.
NXString	GetReferenceAttribute (const NXString &title)
	Gets the reference string (not the calculated value) of a string attribute that uses a reference string.
NXString	GetReferenceAttribute (const char *title)
	Gets the reference string (not the calculated value) of a string attribute that uses a reference string.
NXString	GetStringAttribute (const NXString &title)
	Gets a string attribute value by title.
NXString	GetStringAttribute (const char *title)
	Gets a string attribute value by title.
NXString	GetStringUserAttribute (const NXString &title, int index)
	Gets a string attribute by Title and array Index.
NXString	GetStringUserAttribute (const char *title, int index)
	Gets a string attribute by Title and array Index.
NXString	GetTimeAttribute (NXOpen::NXObject::DateAndTimeFormat format, const NXString &title)
	Gets a time attribute by title.
NXString	GetTimeAttribute (NXOpen::NXObject::DateAndTimeFormat format, const char *title)
	Gets a time attribute by title.
NXString	GetTimeUserAttribute (const NXString &title, int index)
	Gets a time attribute by Title and array Index.
NXString	GetTimeUserAttribute (const char *title, int index)
	Gets a time attribute by Title and array Index.
NXOpen::NXObject::AttributeInformation	GetUserAttribute (const NXString &title, NXOpen::NXObject::AttributeType type, int index)
	Gets the first attribute encountered on the object, if any, with a given Title, Type and array Index.
NXOpen::NXObject::AttributeInformation	GetUserAttribute (const char *title, NXOpen::NXObject::AttributeType type, int index)
	Gets the first attribute encountered on the object, if any, with a given Title, Type and array Index.
NXString	GetUserAttributeAsString (const NXString &title, NXOpen::NXObject::AttributeType type, int index)
	Gets the first attribute encountered on the object, if any, with a given title, type and array index.
NXString	GetUserAttributeAsString (const char *title, NXOpen::NXObject::AttributeType type, int index)
	Gets the first attribute encountered on the object, if any, with a given title, type and array index.
bool	GetUserAttributeLock (const NXString &title, NXOpen::NXObject::AttributeType type)
	Determine the lock of the given attribute.
bool	GetUserAttributeLock (const char *title, NXOpen::NXObject::AttributeType type)
	Determine the lock of the given attribute.
std::vector < NXOpen::NXObject::AttributeInformation >	GetUserAttributes ()
	Gets all the attributes that have been set on the given object.
std::vector < NXOpen::NXObject::AttributeInformation >	GetUserAttributes (bool includeUnset)
	Gets all the attributes that have been set on the given object.
std::vector < NXOpen::NXObject::AttributeInformation >	GetUserAttributes (bool includeUnset, bool addStringValues)
	Gets all the attributes that have been set on the given object.
std::vector< NXString >	GetUserAttributesAsStrings ()
	Gets all the attributes that have been set on the given object.
std::vector< NXOpen::NXObject * >	GetUserAttributeSourceObjects ()
	Returns an array of objects from which this object presents attributes.
bool	HasUserAttribute (const NXString &title, NXOpen::NXObject::AttributeType type, int index)
	Determines if an attribute with the given Title, Type and array Index is present on the object If the attribute is not an array, the Index is ignored (if this is known beforehand, we recommend setting the Index to -1 to save time).
bool	HasUserAttribute (const char *title, NXOpen::NXObject::AttributeType type, int index)
	Determines if an attribute with the given Title, Type and array Index is present on the object If the attribute is not an array, the Index is ignored (if this is known beforehand, we recommend setting the Index to -1 to save time).
virtual bool	IsOccurrence ()
	Returns whether this object is an occurrence or not.
virtual NXString	JournalIdentifier ()
	Returns the identifier that would be recorded in a journal for this object.
virtual NXString	Name ()
	Returns the custom name of the object.
virtual NXOpen::Assemblies::Component *	OwningComponent ()
	Returns the owning component, if this object is an occurrence.
virtual NXOpen::BasePart *	OwningPart ()
	Returns the owning part of this object Created in NX3.0.0.
virtual void	Print ()
	Prints a representation of this object to the system log file.
virtual NXOpen::INXObject *	Prototype ()
	Returns the prototype of this object if it is an occurrence.
void	SetAttribute (const NXString &title, int value)
	Creates or modifies an integer attribute.
void	SetAttribute (const char *title, int value)
	Creates or modifies an integer attribute.
void	SetAttribute (const NXString &title, int value, NXOpen::Update::Option option)
	Creates or modifies an integer attribute with the option to update or not.
void	SetAttribute (const char *title, int value, NXOpen::Update::Option option)
	Creates or modifies an integer attribute with the option to update or not.
void	SetAttribute (const NXString &title, double value)
	Creates or modifies a real attribute.
void	SetAttribute (const char *title, double value)
	Creates or modifies a real attribute.
void	SetAttribute (const NXString &title, double value, NXOpen::Update::Option option)
	Creates or modifies a real attribute with the option to update or not.
void	SetAttribute (const char *title, double value, NXOpen::Update::Option option)
	Creates or modifies a real attribute with the option to update or not.
void	SetAttribute (const NXString &title, const NXString &value)
	Creates or modifies a string attribute.
void	SetAttribute (const char *title, const char *value)
	Creates or modifies a string attribute.
void	SetAttribute (const NXString &title, const NXString &value, NXOpen::Update::Option option)
	Creates or modifies a string attribute with the option to update or not.
void	SetAttribute (const char *title, const char *value, NXOpen::Update::Option option)
	Creates or modifies a string attribute with the option to update or not.
void	SetAttribute (const NXString &title)
	Creates or modifies a null attribute which is an attribute with a title and no value.
void	SetAttribute (const char *title)
	Creates or modifies a null attribute which is an attribute with a title and no value.
void	SetAttribute (const NXString &title, NXOpen::Update::Option option)
	Creates or modifies a null attribute with the option to update or not.
void	SetAttribute (const char *title, NXOpen::Update::Option option)
	Creates or modifies a null attribute with the option to update or not.
void	SetBooleanUserAttribute (const NXString &title, int index, bool value, NXOpen::Update::Option option)
	Creates or modifies a boolean attribute with the option to update or not.
void	SetBooleanUserAttribute (const char *title, int index, bool value, NXOpen::Update::Option option)
	Creates or modifies a boolean attribute with the option to update or not.
virtual void	SetName (const NXString &name)
	Sets the custom name of the object.
void	SetName (const char *name)
	Sets the custom name of the object.
void	SetReferenceAttribute (const NXString &title, const NXString &value)
	Creates or modifies a string attribute which uses a reference string.
void	SetReferenceAttribute (const char *title, const char *value)
	Creates or modifies a string attribute which uses a reference string.
void	SetReferenceAttribute (const NXString &title, const NXString &value, NXOpen::Update::Option option)
	Creates or modifies a string attribute which uses a reference string, with the option to update or not.
void	SetReferenceAttribute (const char *title, const char *value, NXOpen::Update::Option option)
	Creates or modifies a string attribute which uses a reference string, with the option to update or not.
void	SetTimeAttribute (const NXString &title, const NXString &value)
	Creates or modifies a time attribute.
void	SetTimeAttribute (const char *title, const char *value)
	Creates or modifies a time attribute.
void	SetTimeAttribute (const NXString &title, const NXString &value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetTimeAttribute (const char *title, const char *value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetTimeUserAttribute (const NXString &title, int index, const NXString &value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetTimeUserAttribute (const char *title, int index, const char *value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetTimeUserAttribute (const NXString &title, int index, const NXOpen::NXObject::ComputationalTime &value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetTimeUserAttribute (const char *title, int index, const NXOpen::NXObject::ComputationalTime &value, NXOpen::Update::Option option)
	Creates or modifies a time attribute with the option to update or not.
void	SetUserAttribute (const NXOpen::NXObject::AttributeInformation &info, NXOpen::Update::Option option)
	Creates or modifies an attribute with the option to update or not.
void	SetUserAttribute (const NXString &title, int index, int value, NXOpen::Update::Option option)
	Creates or modifies an integer attribute with the option to update or not.
void	SetUserAttribute (const char *title, int index, int value, NXOpen::Update::Option option)
	Creates or modifies an integer attribute with the option to update or not.
void	SetUserAttribute (const NXString &title, int index, double value, NXOpen::Update::Option option)
	Creates or modifies a real attribute with the option to update or not.
void	SetUserAttribute (const char *title, int index, double value, NXOpen::Update::Option option)
	Creates or modifies a real attribute with the option to update or not.
void	SetUserAttribute (const NXString &title, int index, const NXString &value, NXOpen::Update::Option option)
	Creates or modifies a string attribute with the option to update or not.
void	SetUserAttribute (const char *title, int index, const char *value, NXOpen::Update::Option option)
	Creates or modifies a string attribute with the option to update or not.
void	SetUserAttribute (const NXString &title, int index, NXOpen::Update::Option option)
	Creates or modifies a null attribute with the option to update or not.
void	SetUserAttribute (const char *title, int index, NXOpen::Update::Option option)
	Creates or modifies a null attribute with the option to update or not.
void	SetUserAttributeLock (const NXString &title, NXOpen::NXObject::AttributeType type, bool lock)
	Lock or unlock the given attribute.
void	SetUserAttributeLock (const char *title, NXOpen::NXObject::AttributeType type, bool lock)
	Lock or unlock the given attribute.
Public Member Functions inherited from NXOpen::TaggedObject
tag_t	GetTag () const
	<b>Deprecated</b>:<br>    Use Tag instead.
tag_t	Tag () const
	Returns the tag of this object.
Public Member Functions inherited from NXOpen::INXObject
NXOpen::INXObject *	FindObject (const char *journalIdentifier)
	Finds the NXObject with the given identifier as recorded in a journal.
void	SetName (const char *name)
	Sets the custom name of the object.

Detailed Description

Represents a feature on a part
This is an abstract class, and cannot be instantiated.

Created in NX3.0.0.

Member Enumeration Documentation

enum NXOpen::Features::Feature::BooleanType

Boolean operation type.

Enumerator:

BooleanTypeCreate	Create.
BooleanTypeUnite	Unite.
BooleanTypeSubtract	Subtract.
BooleanTypeIntersect	Intersect.
BooleanTypeEmbossOppositeNormalSide	Emboss, keep tool opposite of normal side of sheet.

enum NXOpen::Features::Feature::DiagnosticType

Diagnostic type.

Enumerator:

DiagnosticTypeWarning

Warning.

Member Function Documentation

int NXOpen::Features::Feature::AlgorithmVersion

(

)

Returns the algorithm version of the feature

Deprecated:

Deprecated in NX8.5.0.

Algorithm version is for internal use only. There is no replacement for this method.

Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::ChangeBooleanType

(

)

Change Boolean Type
Created in NX9.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

NXOpen::Features::IContainerFeature* NXOpen::Features::Feature::ContainerFeature

(

)

Returns the container feature for this feature.

Will be set to NULL if this feature is not a contained feature.
Created in NX8.5.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::DeleteClueAlerts

(

)

Delete all clue alerts from the features
Created in NX8.0.1.

License requirements : None

void NXOpen::Features::Feature::DeleteHintAlerts

(

)

Delete all clue alerts from the features
Created in NX8.0.1.

License requirements : None

void NXOpen::Features::Feature::DeleteInformationalAlerts

(

)

Delete all informational alerts from the features
Created in NX5.0.0.

License requirements : None

NXString NXOpen::Features::Feature::FeatureType

(

)

Returns the feature type
Created in NX3.0.0.

License requirements : None

std::vector<NXOpen::Features::Feature *> NXOpen::Features::Feature::GetChildren

(

)

Returns the immediate child features.

Returns

Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

std::vector<NXOpen::NXObject *> NXOpen::Features::Feature::GetEntities

(

)

Returns the entities created by the feature.

Returns

Created in NX4.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

std::vector<NXOpen::Expression *> NXOpen::Features::Feature::GetExpressions

(

)

Returns the expressions created by the feature.

Returns

Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

std::vector<NXString> NXOpen::Features::Feature::GetFeatureClueHintMessages

(

)

Returns both clue and hint messages of the feature.

num_clueHint can be NULL

Returns

Created in NX8.0.1.

License requirements : None

std::vector<NXString> NXOpen::Features::Feature::GetFeatureClueMessages

(

)

Returns the feature clue messages.

clue_messages can be NULL

Returns

Created in NX8.0.1.

License requirements : None

std::vector<NXString> NXOpen::Features::Feature::GetFeatureErrorMessages

(

)

Returns the feature error messages.

error_messages can be NULL

Returns

Created in NX5.0.0.

License requirements : None

std::vector<NXString> NXOpen::Features::Feature::GetFeatureHintMessages

(

)

Returns the feature hint messages.

hint_messages can be NULL

Returns

Created in NX8.0.1.

License requirements : None

std::vector<NXString> NXOpen::Features::Feature::GetFeatureInformationalMessages

(

)

Returns the feature informational messages.

info_messages can be NULL

Returns

Created in NX5.0.0.

License requirements : None

NXString NXOpen::Features::Feature::GetFeatureName

(

)

Returns the displayed name of the feature.

Returns

displayed name
Created in NX6.0.0.

License requirements : None

std::vector<NXString> NXOpen::Features::Feature::GetFeatureWarningMessages

(

)

Returns the feature warning messages.

warning_messages can be NULL

Returns

Created in NX5.0.0.

License requirements : None

std::vector<NXOpen::Features::Feature *> NXOpen::Features::Feature::GetParents

(

)

Returns the immediate parent features.

Returns

Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING")

std::vector<NXOpen::Section *> NXOpen::Features::Feature::GetSections

(

)

Queries a feature for list of its sections.

Returns

Array of sections
Created in NX7.5.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::HideBody

(

)

Hide the body created by the feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::HideParents

(

)

Hide the body created by the parent feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::Highlight

(

)

Highlight the body created by the feature
Created in NX3.0.0.

License requirements : None

bool NXOpen::Features::Feature::IsContainedFeature

(

)

Returns true if the feature is a contained feature.

If it is a contained feature, use the property Features::Feature::ContainerFeature to get the container feature for this feature.

Deprecated:

Deprecated in NX9.0.0. Use Features::Feature::ContainerFeature and check if it is NULL instead.

Created in NX8.5.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

bool NXOpen::Features::Feature::IsInternal

(

)

Returns true if the feature is internal.

Created in NX6.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

NXOpen::Point3d NXOpen::Features::Feature::Location

(

)

Returns the location of the feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::LogDiagnostic	(	int	errorCode,
		const NXString &	message,
		NXOpen::Features::Feature::DiagnosticType	diagnosticType
	)

Log a diagnostic alert for this feature
Created in NX8.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

errorCode	errorcode
message	NOTE: The full Unicode character set is not supported for this parameter.
diagnosticType	diagnostictype

void NXOpen::Features::Feature::LogDiagnostic	(	int	errorCode,
		const char *	message,
		NXOpen::Features::Feature::DiagnosticType	diagnosticType
	)

Log a diagnostic alert for this feature
Created in NX8.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

errorCode	errorcode
message	NOTE: The full Unicode character set is not supported for this parameter.
diagnosticType	diagnostictype

void NXOpen::Features::Feature::MakeCurrentFeature

(

)

Make current feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::MakeSketchExternal

(

)

Make the parent sketch external for reuse by other features.

Created in NX5.0.1.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::MakeSketchInternal

(

)

Make the parent sketch internal if referenced only by this feature.

Created in NX5.0.1.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::RemoveForEdit

(

bool

dependent

)

Remove all the feature faces before a NoHistory mode edit.

Created in NX6.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

dependent

dependent

void NXOpen::Features::Feature::RemoveParameters

(

)

Remove Local feature parameters in history free mode.

Created in NX7.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::SetGroupActive

(

bool

active

)

Set a feature group as active group.

If input is ja_NULL, set no feature group active
Created in NX7.5.1.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

active

active

void NXOpen::Features::Feature::ShowBody

(

bool

moveCurves

)

Show the body created by the feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

moveCurves

move curves

void NXOpen::Features::Feature::ShowDimensions

(

)

Show all feature dimensions of a feature.

Created in NX6.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

void NXOpen::Features::Feature::ShowParents

(

bool

moveCurves

)

Show the body created by the parent feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

Parameters

moveCurves

move curves

void NXOpen::Features::Feature::Suppress

(

)

Suppress the feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

bool NXOpen::Features::Feature::Suppressed

(

)

Returns the suppression status of the feature
Created in NX3.0.0.

License requirements : None

int NXOpen::Features::Feature::Timestamp

(

)

Returns the timestamp of the feature
Created in NX3.0.0.

License requirements : None

void NXOpen::Features::Feature::Unhighlight

(

)

Unhighlight the body created by the feature
Created in NX3.0.0.

License requirements : None

void NXOpen::Features::Feature::Unsuppress

(

)

Unsuppress the feature
Created in NX3.0.0.

License requirements : solid_modeling ("SOLIDS MODELING") OR cam_base ("CAM BASE")

---

The documentation for this class was generated from the following file:

• Features_Feature.hxx
