Represents a container feature on a part. More...
Public Member Functions | |
| virtual std::vector < NXOpen::Features::Feature * > | GetAllContainedFeatures ()=0 |
| Returns all the features contained in this container feature. | |
| virtual std::vector < NXOpen::Body * > | GetAssociatedBodies ()=0 |
| Returns all the bodies created, modified and split by the container feature's "contained" features. | |
| virtual std::vector < NXOpen::DisplayableObject * > | GetAssociatedCurvesPointsDatums ()=0 |
| Returns all the entities(curves,points and datums) created by the container feature's "contained" features. | |
| virtual std::vector < NXOpen::Edge * > | GetAssociatedEdges ()=0 |
| Returns all the edges created, modified and split by the container feature's "contained" features. | |
| virtual std::vector < NXOpen::Face * > | GetAssociatedFaces ()=0 |
| Returns all the faces created, modified and split by the container feature's "contained" features. | |
| virtual std::vector < NXOpen::Features::Feature * > | GetImmediateContainedFeatures ()=0 |
| Returns the Immediate Contained features within the container feature. | |
 Public Member Functions inherited from NXOpen::INXObject | |
| virtual NXOpen::INXObject * | FindObject (const NXString &journalIdentifier)=0 |
| Finds the NXObject with the given identifier as recorded in a journal. | |
| NXOpen::INXObject * | FindObject (const char *journalIdentifier) |
| Finds the NXObject with the given identifier as recorded in a journal. | |
| virtual bool | IsOccurrence ()=0 |
| Returns whether this object is an occurrence or not. | |
| virtual NXString | JournalIdentifier ()=0 |
| Returns the identifier that would be recorded in a journal for this object. | |
| virtual NXString | Name ()=0 |
| Returns the custom name of the object. | |
| virtual NXOpen::Assemblies::Component * | OwningComponent ()=0 |
| Returns the owning component, if this object is an occurrence. | |
| virtual NXOpen::BasePart * | OwningPart ()=0 |
| Returns the owning part of this object Created in NX3.0.0. | |
| virtual void | Print ()=0 |
| Prints a representation of this object to the system log file. | |
| virtual NXOpen::INXObject * | Prototype ()=0 |
| Returns the prototype of this object if it is an occurrence. | |
| virtual void | SetName (const NXString &name)=0 |
| Sets the custom name of the object. | |
| void | SetName (const char *name) |
| Sets the custom name of the object. | |
Detailed Description
Represents a container feature on a part.
A container feature contains and maintains other features which produce or modify geometry.The container feature does not operate on any geometry directly. Features such as Features::PatternFeature and Features::FeatureGroup are examples of container features.
Created in NX8.5.0.
Member Function Documentation
|
pure virtual |
Returns all the features contained in this container feature.
This method will cycle through any container features contained by this container feature to return the complete set of contained features.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
|
pure virtual |
Returns all the bodies created, modified and split by the container feature's "contained" features.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
|
pure virtual |
Returns all the entities(curves,points and datums) created by the container feature's "contained" features.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
|
pure virtual |
Returns all the edges created, modified and split by the container feature's "contained" features.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
|
pure virtual |
Returns all the faces created, modified and split by the container feature's "contained" features.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
|
pure virtual |
Returns the Immediate Contained features within the container feature.
- Returns
Created in NX8.5.0.
License requirements : solid_modeling ("SOLIDS MODELING")
Implemented in NXOpen::Features::InstanceFeature, NXOpen::Features::PatternFeature, and NXOpen::Features::PatternGeometry.
The documentation for this class was generated from the following file:
- Features_IContainerFeature.hxx
