This builder is used to nudge the alignment by a fine adjustment
To create a new instance of this class, use CAE::CorrelManager::CreateCorrelFineTuneAlignmentBuilder
Created in NX9.0.0.
More...
Public Types | |
| enum | AngleVector { AngleVectorXc, AngleVectorYc, AngleVectorZc, AngleVectorNegXc, AngleVectorNegYc, AngleVectorNegZc } |
| the angle vector enumeration for the alignment nudge More... | |
| enum | DistanceVector { DistanceVectorXc, DistanceVectorYc, DistanceVectorZc, DistanceVectorNegXc, DistanceVectorNegYc, DistanceVectorNegZc } |
| the distance vector enumeration for the alignment nudge More... | |
Public Member Functions | |
| NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngleVector | AngleEnum () |
| Returns the angle vector enumeration Created in NX9.0.0. | |
| NXOpen::Expression * | AngularExp () |
| Returns the angular expression Created in NX9.0.0. | |
| NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceVector | DistanceEnum () |
| Returns the distance vector enumeration Created in NX9.0.0. | |
| NXOpen::Expression * | DistanceExp () |
| Returns the distance expression Created in NX9.0.0. | |
| void | MoveButton () |
| The move button to nudge alignment by the defined distance along the selected distance vector Created in NX9.0.0. | |
| void | RotateButton () |
| The rotate button to nudge alignment by the defined angle via the selected angle vector Created in NX9.0.0. | |
| void | SetAngleEnum (NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngleVector angleEnum) |
| Sets the angle vector enumeration Created in NX9.0.0. | |
| void | SetDistanceEnum (NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceVector distanceEnum) |
| Sets the distance vector enumeration Created in NX9.0.0. | |
Detailed Description
This builder is used to nudge the alignment by a fine adjustment
To create a new instance of this class, use CAE::CorrelManager::CreateCorrelFineTuneAlignmentBuilder
Created in NX9.0.0.
Member Enumeration Documentation
Member Function Documentation
| NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngleVector NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngleEnum | ( | ) |
Returns the angle vector enumeration
Created in NX9.0.0.
License requirements : None
| NXOpen::Expression* NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngularExp | ( | ) |
Returns the angular expression
Created in NX9.0.0.
License requirements : None
| NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceVector NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceEnum | ( | ) |
Returns the distance vector enumeration
Created in NX9.0.0.
License requirements : None
| NXOpen::Expression* NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceExp | ( | ) |
Returns the distance expression
Created in NX9.0.0.
License requirements : None
| void NXOpen::CAE::CorrelFineTuneAlignmentBuilder::MoveButton | ( | ) |
The move button to nudge alignment by the defined distance along the selected distance vector
Created in NX9.0.0.
License requirements : nx_correl_base ("FE Correlation")
| void NXOpen::CAE::CorrelFineTuneAlignmentBuilder::RotateButton | ( | ) |
The rotate button to nudge alignment by the defined angle via the selected angle vector
Created in NX9.0.0.
License requirements : nx_correl_base ("FE Correlation")
| void NXOpen::CAE::CorrelFineTuneAlignmentBuilder::SetAngleEnum | ( | NXOpen::CAE::CorrelFineTuneAlignmentBuilder::AngleVector | angleEnum | ) |
Sets the angle vector enumeration
Created in NX9.0.0.
License requirements : nx_correl_base ("FE Correlation")
- Parameters
-
angleEnum angleenum
| void NXOpen::CAE::CorrelFineTuneAlignmentBuilder::SetDistanceEnum | ( | NXOpen::CAE::CorrelFineTuneAlignmentBuilder::DistanceVector | distanceEnum | ) |
Sets the distance vector enumeration
Created in NX9.0.0.
License requirements : nx_correl_base ("FE Correlation")
- Parameters
-
distanceEnum distanceenum
The documentation for this class was generated from the following file:
- CAE_CorrelFineTuneAlignmentBuilder.hxx
