Represents a Drawings::EditViewSettingsBuilder builder. More...
Public Member Functions | |
| void | InheritSettingsFromCustomerDefault () |
| Inherit Settings From Customer Default Created in NX9.0.0. | |
| void | InheritSettingsFromPreferences () |
| Inherit Settings From Preference Created in NX9.0.0. | |
| void | InheritSettingsFromSelectedObjects (NXOpen::Drawings::DraftingView *selectedObject) |
| Inherit Settings From Selected Objects Created in NX9.0.0. | |
| NXOpen::Drawings::ViewCommonViewLabelBuilder * | ViewCommonViewLabel () |
| Returns the view common view label builder Created in NX9.0.0. | |
| NXOpen::Drawings::ViewDetailLabelBuilder * | ViewDetailLabel () |
| Returns the view detail label builder Created in NX9.0.0. | |
| NXOpen::Drawings::ViewLabelBuilder * | ViewLabel () |
| Returns the view label builder Created in NX9.0.0. | |
| NXOpen::Drawings::ViewProjectedLabelBuilder * | ViewProjectedLabel () |
| Returns the view projected label builder Created in NX9.0.0. | |
| NXOpen::Drawings::ViewSectionLabelBuilder * | ViewSectionLabel () |
| Returns the view section label builder Created in NX9.0.0. | |
| NXOpen::Drawings::ViewStyleBuilder * | ViewStyle () |
| Returns the view style builder Created in NX9.0.0. | |
Detailed Description
Represents a Drawings::EditViewSettingsBuilder builder.
It provides an interface for editing view style settings.
This can be used to change one specific view or all views. <br> To create a new instance of this class, use @link Drafting::SettingsManager::CreateDrawingEditViewSettingsBuilder Drafting::SettingsManager::CreateDrawingEditViewSettingsBuilder @endlink <br>
Default values.
| Property | Value |
|---|---|
|
ViewStyle.ViewStyleGeneral.AngleValue |
0.0 |
|
ViewStyle.ViewStyleGeneral.Scale.Denominator |
1.0 |
|
ViewStyle.ViewStyleGeneral.Scale.Numerator |
1.0 |
|
ViewStyle.ViewStyleGeneral.Scale.ScaleType |
Ratio |
|
ViewStyle.ViewStyleOrientation.HingeLine.ReverseDirection |
false |
|
ViewStyle.ViewStyleOrientation.HingeLine.VectorOption |
Inferred |
|
ViewStyle.ViewStyleOrientation.Ovt.AssociativeOrientation |
0 |
Created in NX9.0.0.
Member Function Documentation
| void NXOpen::Drawings::EditViewSettingsBuilder::InheritSettingsFromCustomerDefault | ( | ) |
Inherit Settings From Customer Default
Created in NX9.0.0.
License requirements : drafting ("DRAFTING")
| void NXOpen::Drawings::EditViewSettingsBuilder::InheritSettingsFromPreferences | ( | ) |
Inherit Settings From Preference
Created in NX9.0.0.
License requirements : drafting ("DRAFTING")
| void NXOpen::Drawings::EditViewSettingsBuilder::InheritSettingsFromSelectedObjects | ( | NXOpen::Drawings::DraftingView * | selectedObject | ) |
Inherit Settings From Selected Objects
Created in NX9.0.0.
License requirements : drafting ("DRAFTING")
- Parameters
-
selectedObject The selected drafting view instance object. NULL is not allowed.
| NXOpen::Drawings::ViewCommonViewLabelBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewCommonViewLabel | ( | ) |
Returns the view common view label builder
Created in NX9.0.0.
License requirements : None
| NXOpen::Drawings::ViewDetailLabelBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewDetailLabel | ( | ) |
Returns the view detail label builder
Created in NX9.0.0.
License requirements : None
| NXOpen::Drawings::ViewLabelBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewLabel | ( | ) |
Returns the view label builder
Created in NX9.0.0.
License requirements : None
| NXOpen::Drawings::ViewProjectedLabelBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewProjectedLabel | ( | ) |
Returns the view projected label builder
Created in NX9.0.0.
License requirements : None
| NXOpen::Drawings::ViewSectionLabelBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewSectionLabel | ( | ) |
Returns the view section label builder
Created in NX9.0.0.
License requirements : None
| NXOpen::Drawings::ViewStyleBuilder* NXOpen::Drawings::EditViewSettingsBuilder::ViewStyle | ( | ) |
Returns the view style builder
Created in NX9.0.0.
License requirements : None
The documentation for this class was generated from the following file:
- Drawings_EditViewSettingsBuilder.hxx
