Represents the builder for evaluating fatigue histories. More...
Public Types | |
| enum | FatigueHistoryDataTypeEnum { FatigueHistoryDataTypeEnumAsPerEvent, FatigueHistoryDataTypeEnumStress, FatigueHistoryDataTypeEnumStrain } |
| Fatigue history data type: as per event, stress or strain. More... | |
Public Member Functions | |
| void | AfuFunction () |
| The function is called when the user click the button of Export to AFU Funciton Created in NX8.0.1. | |
| void | EditEvent () |
| The function is called when the user click the button of Edit Event Attributes Created in NX8.0.1. | |
| void | ExportFatigueHistoryToCsv (const NXString &csvFilename) |
| Export fatigue history functions to a csv file. | |
| void | ExportFatigueHistoryToCsv (const char *csvFilename) |
| Export fatigue history functions to a csv file. | |
| NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::FatigueHistoryDataTypeEnum | FatigueHistoryDataType () |
| Returns the fatigue history enum Created in NX8.0.1. | |
| NXString | OutputAfuFileName () |
| Returns the output afu file name. | |
| void | SetFatigueHistoryDataType (NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::FatigueHistoryDataTypeEnum fatigueHistoryDataType) |
| Sets the fatigue history enum Created in NX8.0.1. | |
| void | SetOutputAfuFileName (const NXString &filename) |
| Sets the output afu file name. | |
| void | SetOutputAfuFileName (const char *filename) |
| Sets the output afu file name. | |
 Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
Represents the builder for evaluating fatigue histories.
To create a new instance of this class, use CAE::DurabilityManager::CreateDurabilityEvaluateFatigueHistoryBuilder
Default values.
| Property | Value |
|---|---|
|
FatigueHistoryDataType |
Stress |
Created in NX8.0.1.
Member Enumeration Documentation
Member Function Documentation
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::AfuFunction | ( | ) |
The function is called when the user click the button of Export to AFU Funciton
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::EditEvent | ( | ) |
The function is called when the user click the button of Edit Event Attributes
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::ExportFatigueHistoryToCsv | ( | const NXString & | csvFilename | ) |
Export fatigue history functions to a csv file.
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
- Parameters
-
csvFilename fatigue history functions will be written-out to this file.
NOTE: The full Unicode character set is not supported for this parameter.
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::ExportFatigueHistoryToCsv | ( | const char * | csvFilename | ) |
Export fatigue history functions to a csv file.
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
- Parameters
-
csvFilename fatigue history functions will be written-out to this file.
NOTE: The full Unicode character set is not supported for this parameter.
| NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::FatigueHistoryDataTypeEnum NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::FatigueHistoryDataType | ( | ) |
Returns the fatigue history enum
Created in NX8.0.1.
License requirements : None
| NXString NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::OutputAfuFileName | ( | ) |
Returns the output afu file name.
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::SetFatigueHistoryDataType | ( | NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::FatigueHistoryDataTypeEnum | fatigueHistoryDataType | ) |
Sets the fatigue history enum
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
- Parameters
-
fatigueHistoryDataType fatiguehistorydatatype
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::SetOutputAfuFileName | ( | const NXString & | filename | ) |
Sets the output afu file name.
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
- Parameters
-
filename filename
| void NXOpen::CAE::DurabilityEvaluateFatigueHistoryBuilder::SetOutputAfuFileName | ( | const char * | filename | ) |
Sets the output afu file name.
Created in NX8.0.1.
License requirements : nx_adv_durability ("NX Advanced Durability")
- Parameters
-
filename filename
