Represents a Tooling::UnusedFileManagementBuilder Unused File Management is to manage the unused files of the project. More...
Public Types | |
| enum | FileDirectory { FileDirectoryProjectDirectory, FileDirectoryRecycleBin } |
| the unused file location. More... | |
Public Member Functions | |
| NXOpen::Tooling::UnusedFileManagementBuilder::FileDirectory | ListDir () |
| Returns the listed directory. | |
| bool | SelectAll () |
| Returns the select all option. | |
| void | SetListDir (NXOpen::Tooling::UnusedFileManagementBuilder::FileDirectory listDir) |
| Sets the listed directory. | |
| void | SetSelectAll (bool selectAll) |
| Sets the select all option. | |
 Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
Represents a Tooling::UnusedFileManagementBuilder Unused File Management is to manage the unused files of the project.
To create a new instance of this class, use Tooling::UnusedFileManagementCollection::CreateUnusedFileManagementBuilder
Default values.
| Property | Value |
|---|---|
|
ListDir |
ProjectDirectory |
|
SelectAll |
0 |
Created in NX8.0.0.
Member Enumeration Documentation
Member Function Documentation
| NXOpen::Tooling::UnusedFileManagementBuilder::FileDirectory NXOpen::Tooling::UnusedFileManagementBuilder::ListDir | ( | ) |
Returns the listed directory.
Created in NX8.0.0.
License requirements : None
| bool NXOpen::Tooling::UnusedFileManagementBuilder::SelectAll | ( | ) |
Returns the select all option.
Created in NX8.0.0.
License requirements : None
| void NXOpen::Tooling::UnusedFileManagementBuilder::SetListDir | ( | NXOpen::Tooling::UnusedFileManagementBuilder::FileDirectory | listDir | ) |
Sets the listed directory.
Created in NX8.0.0.
License requirements : prog_die_wizard ("UG/Progressive Die Wizard")
- Parameters
-
listDir listdir
| void NXOpen::Tooling::UnusedFileManagementBuilder::SetSelectAll | ( | bool | selectAll | ) |
Sets the select all option.
Created in NX8.0.0.
License requirements : prog_die_wizard ("UG/Progressive Die Wizard")
- Parameters
-
selectAll selectall
The documentation for this class was generated from the following file:
- Tooling_UnusedFileManagementBuilder.hxx
