Represents a relationship between Routing::SingleDevice objects. More...
Public Types | |
| enum | RelationType { RelationTypeAssociatedEquipment } |
| Specifies the nature of the relationship between the related and relating objects. More... | |
Detailed Description
Represents a relationship between Routing::SingleDevice objects.
<br>
ObjectRelationship is the abstract base class for @link InterfaceTerminalRelationshipBase InterfaceTerminalRelationshipBase@endlink
and @link DeviceRelationship DeviceRelationship@endlink .
<br>
<br> No creator is available in KF because this is an abstract class. <br>
Created in NX4.0.2.
Member Enumeration Documentation
Member Function Documentation
| void NXOpen::Routing::DeviceRelationship::AddRelatedSingleDevice | ( | NXOpen::Routing::SingleDevice * | relatedDevice | ) |
Adds a Routing::SingleDevice to the collection of related Routing::SingleDevice objects.
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
- Parameters
-
relatedDevice The Routing::SingleDevice to add to the set of related objects
| std::vector<NXOpen::Routing::SingleDevice *> NXOpen::Routing::DeviceRelationship::GetRelatedSingleDevices | ( | ) |
Returns the list of related Routing::SingleDevice objects.
The objects in the list are related to the relating Routing::SingleDevice object.
- Returns
- Set of Routing::SingleDevice objects that are related to the Relating SingleDevice
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
| NXOpen::Routing::SingleDevice* NXOpen::Routing::DeviceRelationship::GetRelatingSingleDevice | ( | ) |
Returns the one Routing::SingleDevice to which the other Routing::SingleDevice objects are related.
- Returns
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
| NXOpen::Routing::DeviceRelationship::RelationType NXOpen::Routing::DeviceRelationship::RelationshipType | ( | ) |
Returns the type of the relationship.
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
| void NXOpen::Routing::DeviceRelationship::RemoveRelatedSingleDevice | ( | NXOpen::Routing::SingleDevice * | relatedDevice | ) |
Removes a Routing::SingleDevice from the collection of related Routing::SingleDevice objects.
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
- Parameters
-
relatedDevice The Routing::SingleDevice that is removed from the set of related objects
| void NXOpen::Routing::DeviceRelationship::ReplaceRelatedSingleDevices | ( | const std::vector< NXOpen::Routing::SingleDevice * > & | relatedDevices | ) |
Replaces the collection of related Routing::SingleDevice objects.
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
- Parameters
-
relatedDevices A set of Routing::SingleDevice objects that replaces the current set of related objects
| void NXOpen::Routing::DeviceRelationship::SetRelatingSingleDevice | ( | NXOpen::Routing::SingleDevice * | relatingDevice | ) |
Sets the one Relating Routing::SingleDevice .
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
- Parameters
-
relatingDevice The new Relating device
| void NXOpen::Routing::DeviceRelationship::SetRelationshipType | ( | NXOpen::Routing::DeviceRelationship::RelationType | relationshipType | ) |
Sets the type of the relationship.
Created in NX4.0.2.
License requirements : routing_advanced ("Routing Advanced"), routing_base ("Routing Basic")
- Parameters
-
relationshipType The new type of the relationship
The documentation for this class was generated from the following file:
- Routing_DeviceRelationship.hxx
