This is an abstract class, and cannot be created. More...
Public Member Functions | |
| bool | AllowSlip () |
| Returns the coulping can slip or not. | |
| NXOpen::Mechatronics::SelectPhysicsJoint * | MasterAxisJoint () |
| Returns the master axis joint. | |
| void | SetAllowSlip (bool allowSlip) |
| Sets the coulping can slip or not. | |
| void | SetMasterAxisJoint (NXOpen::Mechatronics::PhysicsJoint *master) |
| Sets the master axis. | |
| void | SetSlaveAxisJoint (NXOpen::Mechatronics::PhysicsJoint *slave) |
| Sets the slave axis. | |
| NXOpen::Mechatronics::SelectPhysicsJoint * | SlaveAxisJoint () |
| Returns the slave axis joint. | |
 Public Member Functions inherited from NXOpen::Mechatronics::PhysicsConstraintBuilder | |
| NXString | Name () |
| Returns the name. | |
| void | SetName (const NXString &name) |
| Sets the name. | |
| void | SetName (const char *name) |
| Sets the name. | |
| Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
This is an abstract class, and cannot be created.
This is an abstract class, and cannot be created.
Created in NX7.5.1.
Member Function Documentation
| bool NXOpen::Mechatronics::CouplingBuilder::AllowSlip | ( | ) |
Returns the coulping can slip or not.
Created in NX7.5.1.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
| NXOpen::Mechatronics::SelectPhysicsJoint* NXOpen::Mechatronics::CouplingBuilder::MasterAxisJoint | ( | ) |
Returns the master axis joint.
This can be a HingeJoint , SlidingJoint and CylindricalJoint .
Created in NX7.5.1.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
| void NXOpen::Mechatronics::CouplingBuilder::SetAllowSlip | ( | bool | allowSlip | ) |
Sets the coulping can slip or not.
Created in NX7.5.1.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
- Parameters
-
allowSlip allowslip
| void NXOpen::Mechatronics::CouplingBuilder::SetMasterAxisJoint | ( | NXOpen::Mechatronics::PhysicsJoint * | master | ) |
Sets the master axis.
Created in NX8.0.0.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
- Parameters
-
master master
| void NXOpen::Mechatronics::CouplingBuilder::SetSlaveAxisJoint | ( | NXOpen::Mechatronics::PhysicsJoint * | slave | ) |
Sets the slave axis.
Created in NX8.0.0.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
- Parameters
-
slave slave
| NXOpen::Mechatronics::SelectPhysicsJoint* NXOpen::Mechatronics::CouplingBuilder::SlaveAxisJoint | ( | ) |
Returns the slave axis joint.
This can be a HingeJoint , SlidingJoint and CylindricalJoint .
Created in NX7.5.1.
License requirements : nx_mcd_core ("MECHATRONICS CONCEPT DESIGNER")
The documentation for this class was generated from the following file:
- Mechatronics_CouplingBuilder.hxx
