Represents a limits data. More...
Public Member Functions | |
| NXOpen::GeometricUtilities::Extend * | EndExtend () |
| Returns the end extend builder. | |
| void | SetSymmetricOption (bool symmetricOption) |
| Sets the symmetric option. | |
| NXOpen::GeometricUtilities::Extend * | StartExtend () |
| Returns the start extend builder. | |
| bool | SymmetricOption () |
| Returns the symmetric option. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
 Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
Represents a limits data.
Created in NX3.0.1.
Member Function Documentation
| NXOpen::GeometricUtilities::Extend* NXOpen::GeometricUtilities::Limits::EndExtend | ( | ) |
Returns the end extend builder.
Created in NX3.0.1.
License requirements : None
| void NXOpen::GeometricUtilities::Limits::SetSymmetricOption | ( | bool | symmetricOption | ) |
Sets the symmetric option.
Created in NX4.0.0.
License requirements : solid_modeling ("SOLIDS MODELING")
- Parameters
-
symmetricOption symmetric option
| NXOpen::GeometricUtilities::Extend* NXOpen::GeometricUtilities::Limits::StartExtend | ( | ) |
Returns the start extend builder.
Created in NX3.0.1.
License requirements : None
| bool NXOpen::GeometricUtilities::Limits::SymmetricOption | ( | ) |
Returns the symmetric option.
Created in NX4.0.0.
License requirements : solid_modeling ("SOLIDS MODELING")
|
virtual |
Validate whether the inputs to the component are sufficient for commit to be called.
If the component is not in a state to commit then an exception is thrown. For example, if the component requires you to set some property, this method will throw an exception if you haven't set it. This method throws a not-yet-implemented NXException for some components.
- Returns
- Was self validation successful
Created in NX3.0.1.
License requirements : None
Implements NXOpen::GeometricUtilities::IComponentBuilder.
The documentation for this class was generated from the following file:
- GeometricUtilities_Limits.hxx
