This class is used to specify the "container" part for the Ship Structures application, i.e., that part that should have newly created Ship Stiffeners, Plates, Standard Parts added to it as assembly components. More...
Public Member Functions | |
| NXString | ContainerName () |
| Returns the name used in generating Item IDs for newly created Ship objects. | |
| NXString | ContainerPart () |
| Returns the part to which are added newly created Ship objects. | |
| void | SetContainerName (const NXString &containerName) |
| Sets the name used in generating Item IDs for newly created Ship objects. | |
| void | SetContainerName (const char *containerName) |
| Sets the name used in generating Item IDs for newly created Ship objects. | |
| void | SetContainerPart (const NXString &containerPart) |
| Sets the part to which are added newly created Ship objects. | |
| void | SetContainerPart (const char *containerPart) |
| Sets the part to which are added newly created Ship objects. | |
 Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
This class is used to specify the "container" part for the Ship Structures application, i.e., that part that should have newly created Ship Stiffeners, Plates, Standard Parts added to it as assembly components.
It also holds the "container" name which is used in the generation of Teamcenter Item IDs for newly created components.
To create a new instance of this class, use Features::ShipCollection::CreateShipContainerBuilder
Created in NX8.0.0.
Member Function Documentation
| NXString NXOpen::Features::ShipDesign::ShipContainerBuilder::ContainerName | ( | ) |
Returns the name used in generating Item IDs for newly created Ship objects.
Created in NX8.0.0.
License requirements : None
| NXString NXOpen::Features::ShipDesign::ShipContainerBuilder::ContainerPart | ( | ) |
Returns the part to which are added newly created Ship objects.
Created in NX8.0.0.
License requirements : None
| void NXOpen::Features::ShipDesign::ShipContainerBuilder::SetContainerName | ( | const NXString & | containerName | ) |
Sets the name used in generating Item IDs for newly created Ship objects.
Created in NX8.0.0.
License requirements : nx_ship_basic ("Ship Basic Design") OR nx_ship_detail ("Ship Detail Design") OR nx_ship_mfg_prep ("Ship Manufacturing")
- Parameters
-
containerName containername
| void NXOpen::Features::ShipDesign::ShipContainerBuilder::SetContainerName | ( | const char * | containerName | ) |
Sets the name used in generating Item IDs for newly created Ship objects.
Created in NX8.0.0.
License requirements : nx_ship_basic ("Ship Basic Design") OR nx_ship_detail ("Ship Detail Design") OR nx_ship_mfg_prep ("Ship Manufacturing")
- Parameters
-
containerName containername
| void NXOpen::Features::ShipDesign::ShipContainerBuilder::SetContainerPart | ( | const NXString & | containerPart | ) |
Sets the part to which are added newly created Ship objects.
Created in NX8.0.0.
License requirements : nx_ship_basic ("Ship Basic Design") OR nx_ship_detail ("Ship Detail Design") OR nx_ship_mfg_prep ("Ship Manufacturing")
- Parameters
-
containerPart containerpart
| void NXOpen::Features::ShipDesign::ShipContainerBuilder::SetContainerPart | ( | const char * | containerPart | ) |
Sets the part to which are added newly created Ship objects.
Created in NX8.0.0.
License requirements : nx_ship_basic ("Ship Basic Design") OR nx_ship_detail ("Ship Detail Design") OR nx_ship_mfg_prep ("Ship Manufacturing")
- Parameters
-
containerPart containerpart
The documentation for this class was generated from the following file:
- Features_ShipDesign_ShipContainerBuilder.hxx
