Represents a Display::ExtractScene
This class is restricted to being called from a program running during an Interactive NX session.
More...
Public Member Functions | |
| std::vector< NXString > | GetSceneDescription () |
| Returns the scene description. | |
| void | ImageFileSelect () |
| Gets an image file using file selection. | |
| void | Information () |
| The scene information Created in NX5.0.0. | |
| NXString | SceneName () |
| Returns the scene name Created in NX5.0.0. | |
| void | SetSceneDescription (const std::vector< NXString > &sceneDescription) |
| Sets the scene description Created in NX5.0.0. | |
| void | SetSceneName (const NXString &sceneName) |
| Sets the scene name Created in NX5.0.0. | |
| void | SetSceneName (const char *sceneName) |
| Sets the scene name Created in NX5.0.0. | |
 Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
Represents a Display::ExtractScene
This class is restricted to being called from a program running during an Interactive NX session.
If run from a non-interactive session it will return NULL.
To create a new instance of this class, use ViewCollection::CreateExtractScene
Created in NX5.0.0.
Member Function Documentation
| std::vector<NXString> NXOpen::Display::ExtractScene::GetSceneDescription | ( | ) |
Returns the scene description.
- Returns
Created in NX5.0.0.
License requirements : None
| void NXOpen::Display::ExtractScene::ImageFileSelect | ( | ) |
Gets an image file using file selection.
Created in NX5.0.0.
License requirements : None
| void NXOpen::Display::ExtractScene::Information | ( | ) |
The scene information
Created in NX5.0.0.
License requirements : None
| NXString NXOpen::Display::ExtractScene::SceneName | ( | ) |
Returns the scene name
Created in NX5.0.0.
License requirements : None
| void NXOpen::Display::ExtractScene::SetSceneDescription | ( | const std::vector< NXString > & | sceneDescription | ) |
Sets the scene description
Created in NX5.0.0.
License requirements : None
- Parameters
-
sceneDescription scenedescription
| void NXOpen::Display::ExtractScene::SetSceneName | ( | const NXString & | sceneName | ) |
Sets the scene name
Created in NX5.0.0.
License requirements : None
- Parameters
-
sceneName scenename
| void NXOpen::Display::ExtractScene::SetSceneName | ( | const char * | sceneName | ) |
Sets the scene name
Created in NX5.0.0.
License requirements : None
- Parameters
-
sceneName scenename
The documentation for this class was generated from the following file:
- Display_ExtractScene.hxx
