Represents a Features::ShipDesign::VerifyPenetrationBuilder builder
To create a new instance of this class, use Features::ShipDesign::PenetrationRequestCollection::CreateVerifyPenetrationBuilder
Created in NX8.5.0.
More...
Public Types | |
| enum | SelectionDialogType { SelectionDialogTypeStructureForRequest, SelectionDialogTypeRouteForRequest, SelectionDialogTypeStructureForVerify, SelectionDialogTypeRouteForVerify = 4 } |
| Represents the selection dialog type. More... | |
Public Member Functions | |
| NXOpen::Routing::RouteObjectCollector * | RoutingObjectCollector () |
| Returns the route object collector Created in NX8.5.0. | |
| NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SelectionDialogType | SelectionType () |
| Returns the dialog selection type Created in NX8.5.0. | |
| void | SetSelectionType (NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SelectionDialogType selectionType) |
| Sets the dialog selection type Created in NX8.5.0. | |
| NXOpen::SelectNXObjectList * | StructurePartCollector () |
| Returns the selected parts Created in NX8.5.0. | |
 Public Member Functions inherited from NXOpen::Builder | |
| NXOpen::NXObject * | Commit () |
| Commits any edits that have been applied to the builder. | |
| void | Destroy () |
| Deletes the builder, and cleans up any objects created by the builder. | |
| std::vector< NXOpen::NXObject * > | GetCommittedObjects () |
| For builders that create more than one object, this method returns the objects that are created by commit. | |
| NXOpen::NXObject * | GetObject () |
| Returns the object currently being edited by this builder. | |
| void | ShowResults () |
| Updates the model to reflect the result of an edit to the model for all builders that support showing results. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Detailed Description
Represents a Features::ShipDesign::VerifyPenetrationBuilder builder
To create a new instance of this class, use Features::ShipDesign::PenetrationRequestCollection::CreateVerifyPenetrationBuilder
Created in NX8.5.0.
Member Enumeration Documentation
Member Function Documentation
| NXOpen::Routing::RouteObjectCollector* NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::RoutingObjectCollector | ( | ) |
Returns the route object collector
Created in NX8.5.0.
License requirements : None
| NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SelectionDialogType NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SelectionType | ( | ) |
Returns the dialog selection type
Created in NX8.5.0.
License requirements : None
| void NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SetSelectionType | ( | NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::SelectionDialogType | selectionType | ) |
Sets the dialog selection type
Created in NX8.5.0.
License requirements : nx_penetration_mgmt ("Penetration Management")
- Parameters
-
selectionType selectiontype
| NXOpen::SelectNXObjectList* NXOpen::Features::ShipDesign::VerifyPenetrationBuilder::StructurePartCollector | ( | ) |
Returns the selected parts
Created in NX8.5.0.
License requirements : None
The documentation for this class was generated from the following file:
- Features_ShipDesign_VerifyPenetrationBuilder.hxx
