Represents a Builder for Centerline2dSettings. More...
Public Member Functions | |
| double | Extension () |
| Returns the extension parameter for 2D Centerline Created in NX6.0.0. | |
| bool | IndividualDistance () |
| Returns the individual extension distance On/Off parameter for 2D Centerline Created in NX6.0.0. | |
| void | SetExtension (double extension) |
| Sets the extension parameter for 2D Centerline Created in NX6.0.0. | |
| void | SetIndividualDistance (bool individualDistance) |
| Sets the individual extension distance On/Off parameter for 2D Centerline Created in NX6.0.0. | |
| void | SetSize (double size) |
| Sets the short dash size parameter for 2D Centerline Created in NX6.0.0. | |
| double | Size () |
| Returns the short dash size parameter for 2D Centerline Created in NX6.0.0. | |
 Public Member Functions inherited from NXOpen::Annotations::CenterlineSettingsBuilder | |
| NXOpen::NXColor * | Color () |
| Returns the color of centerline Created in NX6.0.0. | |
| double | Gap () |
| Returns the gap parameter for centeline Created in NX6.0.0. | |
| void | SetColor (NXOpen::NXColor *color) |
| Sets the color of centerline Created in NX6.0.0. | |
| void | SetGap (double gap) |
| Sets the gap parameter for centeline Created in NX6.0.0. | |
| void | SetWidth (NXOpen::Annotations::CenterlineSettingsBuilder::CenterlineThickness width) |
| Sets the width of centerline Created in NX6.0.0. | |
| virtual bool | Validate () |
| Validate whether the inputs to the component are sufficient for commit to be called. | |
| NXOpen::Annotations::CenterlineSettingsBuilder::CenterlineThickness | Width () |
| Returns the width of centerline Created in NX6.0.0. | |
| Public Member Functions inherited from NXOpen::TaggedObject | |
| tag_t | GetTag () const |
<b>Deprecated</b>:<br> Use Tag instead. | |
| tag_t | Tag () const |
| Returns the tag of this object. | |
Additional Inherited Members | |
| Public Types inherited from NXOpen::Annotations::CenterlineSettingsBuilder | |
| enum | CenterlineThickness { CenterlineThicknessThin, CenterlineThicknessNormal, CenterlineThicknessThick, CenterlineThicknessOne = 6, CenterlineThicknessTwo, CenterlineThicknessThree, CenterlineThicknessFour, CenterlineThicknessFive, CenterlineThicknessSix, CenterlineThicknessSeven, CenterlineThicknessEight, CenterlineThicknessNine } |
| the types of centerline thickness More... | |
Detailed Description
Represents a Builder for Centerline2dSettings.
Created in NX6.0.0.
Member Function Documentation
| double NXOpen::Annotations::Centerline2dSettingsBuilder::Extension | ( | ) |
Returns the extension parameter for 2D Centerline
Created in NX6.0.0.
License requirements : None
| bool NXOpen::Annotations::Centerline2dSettingsBuilder::IndividualDistance | ( | ) |
Returns the individual extension distance On/Off parameter for 2D Centerline
Created in NX6.0.0.
License requirements : None
| void NXOpen::Annotations::Centerline2dSettingsBuilder::SetExtension | ( | double | extension | ) |
Sets the extension parameter for 2D Centerline
Created in NX6.0.0.
License requirements : drafting ("DRAFTING")
- Parameters
-
extension extension
| void NXOpen::Annotations::Centerline2dSettingsBuilder::SetIndividualDistance | ( | bool | individualDistance | ) |
Sets the individual extension distance On/Off parameter for 2D Centerline
Created in NX6.0.0.
License requirements : drafting ("DRAFTING")
- Parameters
-
individualDistance individualdistance
| void NXOpen::Annotations::Centerline2dSettingsBuilder::SetSize | ( | double | size | ) |
Sets the short dash size parameter for 2D Centerline
Created in NX6.0.0.
License requirements : drafting ("DRAFTING")
- Parameters
-
size size
| double NXOpen::Annotations::Centerline2dSettingsBuilder::Size | ( | ) |
Returns the short dash size parameter for 2D Centerline
Created in NX6.0.0.
License requirements : None
The documentation for this class was generated from the following file:
- Annotations_Centerline2dSettingsBuilder.hxx
