Center Point, Existing Line Example

Creating a cone by specifying a line and a center point.

$$
$$  Declarations
$$
    ENTITY/PT1,LN1,CN1
$$
$$ Geometry Definition
$$
    PT1=POINT/0,0
    LN1=LINE/2,0,1,1
$$
$$ Cone Definition
$$
    CN1=CONE/CENTER,PT1,VECT,0,1,0,LN1

Cone Generated by Revolving a Line about an Imaginary Axis
